| Specification | Details |
|---|---|
| Dimensions | 89 × 46 × 33 mm (3.5 × 1.8 × 1.3″) |
| Weight | 100 g (3.5 oz) |
| Power Cable | Included |
| Input Voltage Range | 100–240V AC |
| Input Frequency | 50/60Hz |
| Output Voltage | 24V |
| Rated Voltage | 24V |
| LAN Activity Indicator | — |
| Connector | C6 |
| Networking Interface | RJ45 |
| Gigabit LAN Port | ✓ |
| Remote Reset Capability | ✓ |
| Reset Button | ✓ |
| 2-pair Powering | Pins 4, 5 (+) and Pins 3, 6, 7, 8 (-) |
| AC Connector | IEC-320 C6 |
| Output Current | 0.5A |
| Data In / PoE | RJ45 shielded socket |
| Input Current | 0.3A @ 120V AC; 0.2A @ 240V AC |
| Inrush Current | <30A peak @ 120V AC; <60A peak @ 230V AC |
| Efficiency | 82.96% |
| Switching Frequency | 50 kHz |
| Output Ripple | 1% Max. |
| Line Regulation | ≤ 3% |
| Load Regulation | ≤ 5% |
| Max. Surge Discharge | 1500A (8/20 µs) power |
| Peak Pulse Current | 36A (10/1000 µs) data |
| Max. Power Consumption | 0.1W |
| Response Time | <1 ns |
| Shunt Capacitance | <5 pF data |
| Supported Voltage Range | 22.8–25.2V |
| Total Output Power | 12W |
| Over Current Protection | 0.6–1A |
| Surge Protection | Differential and Common Mode |
| ESD/EMP Protection | 6KV/10KV |
| Ambient Storage Temperature | -30 to 70°C (-22 to 158°F) |
| Ambient Operating Temperature | 0 to 40°C (32 to 104°F) |
| Ambient Operating Humidity | 5 to 95%, noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, UL, PSE, BSMI |
