Sale!

Ubiquiti Lite Beam Gen2

Name: Ubiquiti Lite Beam Gen2
SKU: 2541
Price: 26500 PKR
Availability: InStock

Original price was: ₨ 35,000.Current price is: ₨ 26,500.

Ubiquiti PowerBeam 5AC Gen 2 (Model: PBE-5AC-Gen2) is a high-performance 5 GHz airMAX ac bridge designed for long-range point-to-point (PtP) and point-to-multipoint (PtMP) connections

Category: UBIQUITI Tags: gen2, litebeam gen2, PBE-5AC-GEN2, ubiquiti, ubiquiti antena, ubiquiti best products, ubiquiti lite beam gen2, ubiquiti products in pakistan

Description
Reviews (0)

UBIQUITI POWERBEAM 5AC GEN2

MODEL: PBE-5AC-GEN2

TECHNICAL SPECIFICATIONS

1. PHYSICAL & POWER SPECIFICATIONS

Specification	Details
Dimensions	420 × 420 × 230 mm (16.54 × 16.54 × 9.06 in)
Weight	2.22 kg (4.89 lbs)
Power Supply	24V, 0.5A Gigabit PoE Adapter (Included)
Maximum Power Consumption	8.5W
Power Method	Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range	20–26 VDC
Mounting	Pole-Mounting Kit (Included)

2. WIRELESS SPECIFICATIONS

Specification	Details
Antenna Gain	25 dBi
Maximum TX Output Power	24 dBm
Wireless Technology	airMAX ac
Operating Frequency (Worldwide)	5150–5875 MHz
Management Radio (Worldwide)	2412–2472 MHz
Management Radio (USA)	2412–2462 MHz
PtP Channel Width	10/20/30/40/50/60/80 MHz
PtMP Channel Width	10/20/30/40 MHz

3. NETWORK & HARDWARE

Specification	Details
Networking Interface	1 × 10/100/1000 Mbps Ethernet Port
Processor	MIPS 74Kc
Memory	64 MB
LED Indicators	Power, Ethernet, 4 × Signal Strength
Antenna Design	Dish Reflector

4. USA OPERATING FREQUENCY BANDS

Frequency Band	Range
U-NII-1	5150–5250 MHz
U-NII-2A	5250–5350 MHz
U-NII-2C	5470–5725 MHz
U-NII-3	5725–5850 MHz

5. TRANSMIT POWER (TX) SPECIFICATIONS

Modulation	Average TX Power	Tolerance
1x BPSK (½)	24 dBm	±2 dB
2x QPSK (½)	24 dBm	±2 dB
2x QPSK (¾)	24 dBm	±2 dB
4x 16QAM (½)	24 dBm	±2 dB
4x 16QAM (¾)	24 dBm	±2 dB
6x 64QAM (⅔)	23 dBm	±2 dB
6x 64QAM (¾)	23 dBm	±2 dB
6x 64QAM (⅚)	22 dBm	±2 dB
8x 256QAM (¾)	20 dBm	±2 dB
8x 256QAM (⅚)	20 dBm	±2 dB

6. RECEIVER SENSITIVITY (RX) SPECIFICATIONS

Modulation	Sensitivity	Tolerance
1x BPSK (½)	-96 dBm (Min.)	±2 dB
2x QPSK (½)	-95 dBm	±2 dB
2x QPSK (¾)	-92 dBm	±2 dB
4x 16QAM (½)	-90 dBm	±2 dB
4x 16QAM (¾)	-86 dBm	±2 dB
6x 64QAM (⅔)	-83 dBm	±2 dB
6x 64QAM (¾)	-77 dBm	±2 dB
6x 64QAM (⅚)	-74 dBm	±2 dB
8x 256QAM (¾)	-69 dBm	±2 dB
8x 256QAM (⅚)	-65 dBm	±2 dB

7. ENVIRONMENTAL SPECIFICATIONS

Specification	Details
Operating Temperature	-40°C to 70°C (-40°F to 158°F)
Operating Humidity	5–95% Noncondensing
Wind Loading	380 N @ 200 km/h (85.4 lbf @ 125 mph)
Wind Survivability	200 km/h (125 mph)
ESD/EMP Protection	Air: ±24 kV; Contact: ±24 kV
Enclosure Materials	UV-Stabilized Plastic, Powder-Coated SPCC

8. COMPLIANCE & CERTIFICATIONS

Specification	Details
RoHS Compliance	Yes
Certifications	CE, FCC, IC
Salt Fog Test	IEC 68-2-11 (ASTM B117)
Vibration Test	IEC 68-2-6
Temperature Shock Test	IEC 68-2-14
UV Test	IEC 68-2-5
Wind-Driven Rain Test	ETS 300 019-1-4
