- Door Station/Video Parameters
- Resolution1920 × 1080
- Lens1/2.7″ CMOS
- FOVHorizontal: 66.2°,Vertical: 37.2°
- Door Station/Audio Parameters
- Audio InputBuilt-in omnidirectional microphone
- Audio OutputBuilt-in loudspeaker
- Door Station/Device Interfaces
- I/O Output1 relay output
- Four-Wire1 four-wire interface (1-ch video input, 1-ch audio input/output, 1-ch power,supply, 1-ch grounding)
- Door Station/General
- Power Supply12 VDC
- Power ConsumptionMax. 5W
- Working Temperature-10° C to + 55° C (14° F to 131° F)
- Working Humidity10% to 90%
- Dimensions128 mm × 42 mm × 24.8 mm
- Indoor Station/Display Parameters
- Operation MethodPhysical button
- Type7-inch colorful TFT LCD
- Resolution800 × 480
- Indoor Station/Audio Parameters
- Audio InputBuilt-in omnidirectional microphone
- Audio OutputBuilt-in loudspeaker
- Audio QualityNoise suppression and echo cancellation
- Indoor Station/General
- Power Supply12 VDC
- Power Consumption≤5 W
- Working Temperature-10° C to + 55° C (14° F to 131° F)
- Working Humidity10% to 90%
- Dimensions (W × H × D)195.8 mm × 132.8 mm × 18.39 mm (7.7″ × 5.2″ ×0.7″)
